Naomoto MF-350E Finishing Mannequin
The finishing mannequin MF-350E is characterized by a simple and efficient use thanks to the intuitive and easy to use operative panel.
The tridimensional finishing through the hot air blowing is perfect for garments with a complex design, and it allows to mantain the fabric’s quality; moreover, the automatic adjustment of the sleeve lenght and the corners allows for the removal of creases.
Description
Advanced Garment Finishing Solution
The Naomoto MF-350E Finishing Mannequin is a high-performance industrial garment finishing machine designed to deliver wrinkle-free results using steam and air technology. It shapes garments efficiently, ensuring a clean and professional finish for modern textile production.
Efficient Steam & Air Shaping System
The Naomoto MF-350E Finishing Mannequin uses controlled steam and air pressure to remove wrinkles and restore garment shape. It ensures uniform finishing across shirts, jackets, and uniforms, improving overall garment presentation.
The finishing mannequin MF-350E is characterized by a particularly simple use and, moreover, is equipped with:
- Automatic shoulder expanders and rear-view window
- tight wrist clamp
- wide split clamp
- anti-crease front clamps
- center clamps with suction
- extensible body
- high-power blowing and adjustable
This specific machine for shirt ironing has been purposely developed for the laundry and tailoring field,
Technical Features of the Finishing Mannequin MF-350E:
- Electricity Supply: 230V 1P 50Hz
- Power Consumption: 1,8 kW
- Air pressure: 5BAR
- Air consumption: 2,1 litres/cycle
- Air tube diameter: 1/2″
- Steam Pressure: 5BAR
- Steam Consumption: 16 Kg/h
- Steam hose diameter: opening 1/2″, exit 1/2″
- Net weight: 215Kg
- Measurements (lenght x width x height): 109,5 x 118 x 168 cm
For the installation the following components will be necessary:
- N. 4 pc | Anchor bolt M12
- N. 1 pc | Sphere valve 1/2
- N. 1 pc | Sphere valve 1/2
- Switch: around 20 A
