BARUDAN BEKS-CLZ Series (Chenille Combination)

Automatically switches from Standard Embroidery to Chenille Embroidery

Auto/Semi-Auto Switching from/to regular embroidery and chenille embroidery.
Stitch file data controls when Automatic Switching is to be utilized.

Automatic Color Change System, Automatic Thread Trimming and Thread Keeping

Automatic color change up to 6 colors. Automatic thread trimming and thread keep ensure high performance and productivity.

Automatic Needle Bar Height Adjustment System

Ten levels of needle height adjustment. Size of chain stitch and height of loop stitch can also be adjusted.

Automatic Needle Bar Raising Function

Smooth frame/material changes are made easier by the movement of needle bars, nipples and presser foot.

Automatic Tension Open / Close Function

Appropriate thread tension can be adjusted automatically for chain stitch, loop stitch and other stitches.

Switch Function of Chain and Loop Stitch

Chain and loop stiches can be changed by the stitch data in the design.

Places current design in the frame automatically

Frame Centering function sets a design in a selected frame automatically.

Prevents machine operation if design is outside of frame limit

Frame Limit function prevents the accidental hitting of the frame. If a design is outside of the frame parameters, the machine will not operate.

Customize operation icons

Can arrange a group of most used icons for easy access based on particular application.

USB conncetion

Import and export designs data saved in USB memory

Bluetooth Design Transfer

Bluetooth Manager networking software allows for the connectivity of up to 7 devices, including Barudan K-Series embroidery machines. Operators can easily drag/drop designs to multiple machines up to 10 times faster compared to serial communication–even large stitch count designs.
Bluetooth receiver and special software “Bluetooth Manager” are required separately

LAN connection

B-NET networking software connects up to 100 machines. Using LAN Ethernet connection, designs can be pushed via Schedule Mode, or pulled by Direct Download Mode. Additional features, such as web-based dashboards, machine status and production reports can be added.
Special networking software is required separately. The number of connection is different depnding on the sotware.

LED

Bobbin Winder (BN-3e)

[Chenille Embroidery] Needle Plate: 3 types (hole diameter: 1.4mm, 1.6mm, 1.8mm)

[Chenille Embroidery] Nipple: 4 types (hole diameter: 1.0mm, 1.1mm, 1.2mm, 1.4mm)

[Chenille Embroidery] Needle: 3 types (#90, #100, #110)
